Tungsten Cubes & Fragments
Tungsten Parts Wyoming manufactures high-density tungsten cubes and fragments in pure and heavy-alloy grades, machined powder-to-part in Laramie, Wyoming. At up to 19.3 g/cc, tungsten concentrates maximum mass into a compact cube for ballast, defense fragment programs, and collector applications.
Why Tungsten Cubes from TPW?
Tungsten concentrates maximum mass into a compact cube - the material of choice for ballast, defense fragment programs, and precision weighting:
- Maximum Mass in Minimum Size: At up to 19.3 g/cc, tungsten packs more weight into a compact cube than any practical alternative.
- Pure & Heavy-Alloy Grades: Available in pure tungsten and WNiFe/WNiCu heavy-alloy grades to match density and machinability needs.
- Precision-Machined Faces & Tolerances: Cubes and fragments machined to your dimensional and surface-finish specifications.
- US-Manufactured & Documented: Certificate of Conformance and full lot traceability on every order from Laramie, Wyoming.
What TPW Makes in Tungsten Cubes & Fragments
High-density cubes and fragments, built to your specification and delivered with full documentation:
- Available in alloy grades from 17.0 to 18.8 g/cm³ per ASTM B777 / AMS7725F
- Certificate of Conformance (C of C) on every order; full lot traceability
- First-article inspection with dimensional and weight verification
- AS9100D and ISO 9001 certified; ITAR-registered; DFARS-compliant; Made in USA
Every tungsten cube order ships with a Certificate of Conformance and full dimensional verification. Direct coordination with our Laramie, Wyoming facility, no distributors or intermediaries. Request a quote with your sizes, grades, and quantities.
Tungsten Cube Size & Weight
| Cube size | Approx. weight (pure W, 19.25 g/cc) |
|---|---|
| 1.0 in | ~0.66 lb / 0.30 kg |
| 1.5 in | ~2.2 lb / 1.0 kg |
| 2.0 in | ~5.3 lb / 2.4 kg |
| 2.5 in | ~10.3 lb / 4.7 kg |
| 3.0 in | ~17.8 lb / 8.1 kg |
| 4.0 in | ~42 lb / 19 kg |
Tungsten Cubes for Sale
Tungsten cubes are available in standard sizes from 1 inch up, plus larger and custom dimensions. The same density that makes a tungsten cube a popular desk object and collector piece, a 1.5-inch cube weighs about 2.2 pounds, makes alloy cubes and fragments critical components in defense programs. We supply both pure tungsten collector cubes and defense-grade alloy cubes and fragments; request a quote for sizes and pricing.
Frequently Asked Questions
Why is a tungsten cube so heavy?
Tungsten's density is 19.25 g/cc - about 1.7x lead and 2.5x steel - so a cube small enough to hold in one hand can weigh over two pounds.
How much does a 1kg tungsten cube cost?
Pricing depends on material grade, finish, and quantity - request a quote for current pricing.
What are tungsten cubes used for?
Beyond collector and desk objects: defense fragments, kinetic-energy components, counterweight elements, and density-reference standards.
See our Tungsten Properties Guide for density details. DFARS 252.225-7052 Sourcing Confirmation available per program.
Standard Tungsten Cube Sizes
Stocked standard cube sizes, held to a dimensional tolerance of ±0.15 mm with a surface finish of Ra 64 microinches or better.
| SKU | Size | SKU | Size | SKU | Size |
|---|---|---|---|---|---|
| TC-1.94 | 1.94 mm | TC-3.33 | 3.33 mm | TC-5.13 | 5.13 mm |
| TC-2.39 | 2.39 mm | TC-3.74 | 3.74 mm | TC-5.5 | 5.50 mm |
| TC-2.65 | 2.65 mm | TC-4.0 | 4.00 mm | TC-6.0 | 6.00 mm |
| TC-2.87 | 2.87 mm | TC-4.37 | 4.37 mm | TC-7.0 | 7.00 mm |
| TC-3.0 | 3.00 mm | TC-4.84 | 4.84 mm | TC-8.0 | 8.00 mm |
| TC-3.1 | 3.10 mm | TC-5.0 | 5.00 mm | TC-10.0 | 10.00 mm |
Standard Rectangle and Hexagon Sizes
The standard tungsten rectangle measures 7.5 mm x 2.5 mm x 2.5 mm. The standard tungsten hexagon measures 4 mm across flats with a 4 mm height. Both carry the same ±0.15 mm tolerance as the cubes, and custom dimensions are machined to your drawing.
Lead Times
In-stock standard sizes ship in 3 to 5 days. Out-of-stock and custom runs take 10 to 12 weeks. Both vary with shape, size, and quantity, so confirm timing when you request a quote.
